Specifications
Physical/Operating Specifications
Maximum Installation Temperature 5601P, 5603, 5621, and 5623: 100°F (38°C)5602, 5604, 5622, and 5624: 150°F (65.6°C)
Operating Humidity Range 5 to 95% RH non-condensing
Dimensions with mounting bracket Diameter: 4.57 inches (11.6cm) Height: 1.69 inches (4.3cm)
Alarm Temperature 5601P, 5603, 5621, and 5623: 135°F (57°C)5602, 5604, 5622, and 5624: 194°F (90°C)
Weight 6 oz. (170 grams)
Rate-of-Rise Threshold 15°F (8.3°C) rise per minute (models 5601P, 5602, 5621, and 5622 only)
Mounting 3½-inch octagonal back box4-inch octagonal back boxSingle gang back box 4-inch square back box with a square to round plaster ring
Electrical Specifications
Operating Voltage / Contact Ratings 6–125VAC / 3A6–28VDC / 1A125VDC / 0.3A250VDC / 0.1A
Input Terminals 14–22 AWG
